774-E15-113R011

TEX774_E15_113R011
Heilind Number:TEX774-E15-113R011
Manufacturer:NorComp
Manufacturer Number:774-E15-113R011
Datasheet:Datasheet
ECAD Model:
3D Model

Description:

IP67 Male 0.370" Footprint D-Sub 15 Position Right Angle PCB Dip Solder

More >>

Specifications

AttributeValue
Product Category:
D-Sub & D-Ribbon Connectors & Accessories D-Sub Connectors
Manufacturer:NorComp
Manufacturer Part Number:NorComp 774-E15-113R011
Series:772-E
Gender:Plug
Termination Method:Solder
Contact Plating:Gold Flash
Maximum Operating Temperature:125 °C
Minimum Operating Temperature:-55 °C
Mount Angle:Right Angle
Number of Positions:15
Shell Material:Steel
Shell Finish:Nickel Plated
Current Rating:5 A
Voltage Rating:250 VAC
SKU:TEX774-E15-113R011

Detailed Description

Introducing the 774-E15-113R011, a rugged IP67-rated D-Sub connector designed for reliable performance in demanding environments. This male plug features a compact 0.370" footprint and a right-angle PCB dip solder termination method, making it ideal for space-constrained applications. With 15 gold flash-plated contacts, it ensures secure and low-resistance connections, suitable for high-speed data transmission. The sturdy steel shell with nickel plating offers excellent durability and corrosion resistance. Operating in a wide temperature range from -55°C to 125°C, it guarantees reliable performance even in extreme conditions. With a current rating of 5A and a voltage rating of 250VAC, this connector is perfect for industrial and commercial applications where reliability is paramount. Upgrade your connectivity with the 774-E15-113R011.
