| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | WAGO |
| Manufacturer Part Number: | WAGO 2706-103 |
| Series: | 2706 |
| Housing Material: | Nylon |
| Mount Type: | Through Hole |
| Termination Method: | Cage Clamp |
| Contact Material: | Electrolytic Copper |
| Contact Plating: | Tin |
| Pitch: | 7.5 mm |
| Number of Poles: | 3 |
| Number of Levels: | 1 |
| Housing Color: | Gray |
| Wire Size: | 20 - 10 AWG |
| Flammability Rating: | UL 94V-0 |
| Current Rating: | 41 A |
| Voltage Rating: | 1000 V |
| Conductor Size: | 20 - 10 AWG |
| Part Aliases: | 27060103 |
| SKU: | WAG2706-103 |
2706-103
| Heilind Number: | WAG2706-103 |
| Manufacturer: | WAGO |
| Manufacturer Number: | 2706-103 |
| ECAD Model: | |
Specifications
Detailed Description
The 2706-103 TRM BLOCK/3 POLE/7.5MM GR is a high-quality terminal block designed for secure and efficient wire connections. Featuring a durable Nylon housing in a sleek gray color, it is UL 94V-0 rated for excellent flame resistance. With a through-hole mount type and cage clamp termination method, installation is quick and easy. The 3-pole design with a 7.5mm pitch allows for multiple wire connections with a current rating of 41A and a voltage rating of 1000V. Made with electrolytic copper contacts plated with tin, it ensures reliable conductivity and corrosion resistance. Compatible with wire sizes ranging from 20 to 10 AWG, it is suitable for a wide range of applications. RoHS compliant, this terminal block meets international standards for environmental responsibility. Ideal for use in connectors, PCB mount terminal blocks, and other high-reliability applications.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
Additional Resources
| Attribute | Value |
|---|---|
| WAGO: | 2706-103 |
| Other Names: | 27060103 |
