1-282822-2

AMP1-282822-2
Heilind Number:AMP1-282822-2
Manufacturer:TE Connectivity
Manufacturer Number:1-282822-2
Datasheet:Datasheet
ECAD Model:
3D Model

Description:

TERMI-BLOK HEADER,ASSY90 12P.

More >>

Specifications

AttributeValue
Product Category:
Pluggable Terminal Blocks & Headers Pluggable Terminal Block Headers
Manufacturer:TE Connectivity
Manufacturer Part Number:TE Connectivity 1-282822-2
Amperage:15 A
Gender:Header
Housing Material:PA 6/6
Number of Contacts:12
Number of Rows:1
Mount Type:Board Mount
Contact Material:CuMg
Pitch:.197 in, 5 mm
Voltage:300 V AC
Mount Angle:Vertical
Block Type:PCB Mount
Package Quantity:100
Contact Amperage:15 A
Number of Positions:12
Housing Color:Green
GPL:124
Tail Length:.138 in, 3.5 mm
Packaging:Box
Operating Temperature Range:-40 - 105 °C, -40 - 221 °F
Circuit Application:Power & Signal
Contact Mating Area Plating:Tin
GPL Description:Industrial
Connector and Contact Terminate To:Printed Circuit Board
Product Code:7744
Connector System:Wire to Board
Stacking Configuration:Side Stackable
ECCN:EAR99
Header Type:Partially Shrouded
Body Color:Green
Interlock:Without
Closed End:Without
Threaded Flange:Without
Contact Mount Style:Through Hole
Mating Angle:180°
Screw Flange:Without
Screwless Terminal Block:No
Part Aliases:1-282822-2
SKU:AMP1-282822-2

Detailed Description

Introducing the TERMI-BLOK HEADER, ASSY90 12P: a versatile and efficient solution for your power and signal connectivity needs. This 12-position header assembly features a 90-degree design, perfect for board mount applications. With a durable PA 6/6 housing in a sleek green finish, it offers reliable performance in industrial settings. Each contact is plated with tin for enhanced conductivity, and with a 15A amperage rating and 300V AC voltage capacity, it ensures safe and secure connections. The 5mm pitch and through-hole mount style make installation a breeze, while its wave solder capability up to 240°C guarantees easy assembly. RoHS compliant and lead-free, this header is not only environmentally friendly but also meets high industry standards. Whether you're integrating power or signal circuits, the TERMI-BLOK HEADER, ASSY90 12P is the perfect choice for your application.
