1513472-5

AMP1513472_5
Heilind Number:AMP1513472-5
Manufacturer:TE Connectivity
Manufacturer Number:1513472-5
Datasheet:Product Specification
ECAD Model:
3D Model

Description:

Stamped Metal Antenna, Dual Band, Bluetooth / Wi-Fi, External Mount, Snap-In, MHF / MHF1 / U.FL, Omnidirectional, Single Port, Gain 3 < 6 dBi

More >>

Specifications

AttributeValue
Product Category:
Passives Antennas
Manufacturer:TE Connectivity
Manufacturer Part Number:TE Connectivity 1513472-5
Impedance:50 Ω
Polarization:Linear
Protocol:802.11a, 802.11b, 802.11g, 802.11n, Bluetooth, ZigBee
Mounting Style:Snap In
VSWR:3:1
Antenna Type:Stamped Metal
Antenna Termination Type:MHF, MHF1, U.FL, UMCC
Application:Bluetooth, Wi-Fi
Band Type:Dual Band
Center Frequency:2550 MHz, 5850 MHz
Directionality:Omnidirectional
Frequency Range:2480 - 2620 MHz, 5500 - 6200 MHz
Gain:3 dB
SKU:AMP1513472-5

Detailed Description

Enhance your connectivity with this Stamped Metal Antenna, designed for seamless Bluetooth and Wi-Fi performance. Featuring a dual-band operation, it ensures reliable signal transmission for a range of applications. With an external mount and snap-in design, installation is quick and convenient. The omnidirectional orientation and single port configuration offer versatile placement options. Boasting a gain of 3 < 6 dBi, this antenna delivers impressive signal strength. RoHS compliant and compatible with MHF, MHF1, and U.FL connectors, it meets stringent industry standards. Covering frequencies from 2480 to 2620 MHz and 5500 to 6200 MHz, it is ideal for ZigBee, Bluetooth, and various Wi-Fi protocols. Trust in this antenna for efficient and high-performance wireless communication.
