1513472-7

AMP1513472_7
Heilind Number:AMP1513472-7
Manufacturer:TE Connectivity
Manufacturer Number:1513472-7
Datasheet:Product Specification
ECAD Model:
3D Model

Description:

Stamped Metal Antenna, Dual Band, Bluetooth / Wi-Fi, External Mount, Snap-In, MHF / MHF1 / U.FL, Omnidirectional, Single Port, Gain 3 < 6 dBi

More >>

Specifications

AttributeValue
Product Category:
Passives Antennas
Manufacturer:TE Connectivity
Manufacturer Part Number:TE Connectivity 1513472-7
Impedance:50 Ω
Polarization:Linear
Protocol:802.11a, 802.11b, 802.11g, 802.11n, Bluetooth, ZigBee
Mounting Style:Snap In
VSWR:3:1
Antenna Type:Stamped Metal
Antenna Termination Type:MHF, MHF1, U.FL, UMCC
Application:Bluetooth, Wi-Fi
Band Type:Dual Band
Center Frequency:2550 MHz, 5850 MHz
Directionality:Omnidirectional
Frequency Range:2480 - 2620 MHz, 5500 - 6200 MHz
Gain:3 dB
SKU:AMP1513472-7

Detailed Description

Enhance your connectivity with this RoHS-compliant Dual Band Stamped Metal Antenna, designed for Bluetooth and Wi-Fi applications. With a 3 dB gain and omnidirectional directionality, it ensures reliable signal reception in both the 2480 - 2620 MHz and 5500 - 6200 MHz frequency ranges. Featuring a snap-in mounting style and compatibility with MHF, MHF1, U.FL, and UMCC terminations, it offers easy installation for seamless integration. Perfect for ZigBee, Bluetooth, and various 802.11 protocols, this antenna guarantees optimal performance with a VSWR of 3:1 and 50 Ω impedance. Upgrade your wireless setup with this high-quality, external mount antenna.
