1586022-5

AMP1586022-5
Heilind Number:AMP1586022-5
Manufacturer:TE Connectivity
Manufacturer Number:1586022-5
Datasheet:Datasheet
ECAD Model:
3D Model

Description:

5P S/R PM PLUG VAL-U-LOK V2

More >>

Specifications

AttributeValue
Product Category:
Connectors Power Connectors
Manufacturer:TE Connectivity
Manufacturer Part Number:TE Connectivity 1586022-5
Housing Material:Nylon 6/6
Number of Rows:1
Mount Type:Panel
Termination Method:Crimp
Pitch:.165 in, 4.2 mm
Voltage:600 V AC
Contact Type:Pin
Package Quantity:1000
Cable Type:Discrete Wire
Number of Positions:5
Housing Color:White
GPL:G31
Packaging:Bag/Box
Operating Temperature Range:-40 - 105 °C, -40 - 221 °F
Circuit Application:Power & Signal
Connector Height:.291 in, 7.4 mm
Sealable:No
GPL Description:Appliances
Connector and Contact Terminate To:Wire & Cable
Product Code:K924
Contact Layout:Inline
Connector Length:22.2 mm, .874 in
Connector System:Wire to Wire
CSA Agency Certification:208567
Connector Product Type:Housing
ECCN:EAR99
Connector Width:23.9 mm, .94 in
Accepts Wire Insulation Diameter:.047 - .122 in, 1.2 - 3.1 mm
Insertion Force:15 Newton
Contact Retention:Without
Glow Wire Rating:Standard Part - Not Glow Wire
Circuit Identification Feature:With
VDE Tested:No
Connector and Housing Type:Plug
Standards Met:CSA UL
Material Flammability Standard:UL 94V-0
Part Aliases:1586022-5
SKU:AMP1586022-5

Detailed Description

Enhance power and signal connectivity with our 5-position Inline Housing Connector. Designed for optimal performance, this connector features a durable Nylon 6/6 housing in a sleek white finish, meeting CSA and UL standards for quality assurance. With a 4.2mm pitch and crimp termination method, it ensures secure and efficient cable connections in various applications. Operating in a wide temperature range from -40 to 105°C (-40 to 221°F), it offers reliable functionality even in harsh environments. Ideal for appliances and other electronic devices, this connector is RoHS compliant, guaranteeing its environmental responsibility. Whether for professional installations or DIY projects, its easy panel mount design and package quantity of 1000 make it a convenient choice for any wiring setup. Trust in its high voltage AC rating of 600V and UL 94V-0 flammability standard, delivering peace of mind in every connection. Elevate your connectivity solutions with this essential Wire to Wire connector.
