1586024-4

AMP1586024-4
Heilind Number:AMP1586024-4
Manufacturer:TE Connectivity
Manufacturer Number:1586024-4
Datasheet:Datasheet
ECAD Model:
3D Model

Description:

4P S/R FH PLUG VAL-U-LOK V2

More >>

Specifications

AttributeValue
Product Category:
Connectors Power Connectors
Manufacturer:TE Connectivity
Manufacturer Part Number:TE Connectivity 1586024-4
Housing Material:Nylon 6/6
Number of Rows:1
Mount Type:Panel
Termination Method:Crimp
Pitch:.165 in, 4.2 mm
Voltage:600 V AC
Contact Type:Pin
Package Quantity:1000
Cable Type:Discrete Wire
Number of Positions:4
Housing Color:Natural
GPL:G31
Packaging:Bag/Box
Operating Temperature Range:-40 - 105 °C, -40 - 221 °F
Circuit Application:Power & Signal
Connector Height:.291 in, 7.4 mm
Sealable:No
GPL Description:Appliances
Connector and Contact Terminate To:Wire & Cable
Product Code:K924
Contact Layout:Inline
Connector Length:18 mm, .709 in
Connector System:Wire to Wire
CSA Agency Certification:208567
Connector Product Type:Housing
ECCN:EAR99
Connector Width:23.8 mm, .937 in
Accepts Wire Insulation Diameter:.047 - .122 in, 1.2 - 3.1 mm
Insertion Force:15 Newton
Contact Retention:Without
Glow Wire Rating:Standard Part - Not Glow Wire
Circuit Identification Feature:With
VDE Tested:No
Connector and Housing Type:Plug
Standards Met:CSA UL
Material Flammability Standard:UL 94V-2
Part Aliases:1586024-4
SKU:AMP1586024-4

Detailed Description

Meet industry standards with our CSA and UL-certified Inline Housing Connector, perfect for power and signal applications. Featuring a durable Nylon 6/6 construction in a natural color, this connector is designed for panel mounting and accepts discrete wire with a termination method of crimping. With a pitch of 4.2mm (.165 in) and a maximum voltage of 600V AC, it offers reliable connectivity in a wide range of environments. Each package contains 1000 units, making it ideal for bulk installations. Operating temperatures ranging from -40°C to 105°C (-40°F to 221°F) ensure performance in various conditions. With a compact design and a connector height of 7.4mm (.291 in), it is suitable for space-constrained applications. RoHS compliant and suitable for appliances, this connector is a versatile solution for your connectivity needs.
