166500-4

AMP166500-4
Heilind Number:AMP166500-4
Manufacturer:TE Connectivity
Manufacturer Number:166500-4
Datasheet:3D Model (IGS)
ECAD Model:
3D Model

Description:

TANDEM SPR. F. CRIMP

More >>

Specifications

AttributeValue
Product Category:
Pin & Socket Housings & Contacts Pin & Socket Contacts
Manufacturer:TE Connectivity
Manufacturer Part Number:TE Connectivity 166500-4
Mount Type:Cable Mount (Free-Hanging)
Contact Type:Socket
Package Quantity:14000
Contact Amperage:3 A
GPL:401
Operating Temperature Range:-65 - 105 °C, -85 - 221 °F
Circuit Application:Power & Signal
Contact Mating Area Plating:Gold
Contact Mating Area Plating Thickness:50 µin
PCB Retention:Without
PCB Contact Termination Area Plating:Gold Flash
Sealable:No
GPL Description:Data and Devices
Connector and Contact Terminate To:Wire & Cable
Product Code:5250
Wire Size:20 - 24 AWG, .21 - .51 mm²
Connector System:Cable-to-Cable
Wire Insulation Support:With
Accepts Wire Insulation Diameter:.91 - 1.37 mm
Contact Orientation:Straight
Contact Retention Type in Housing:Crimp Snap-In
Amperage:3 A
Part Aliases:166500-4
SKU:AMP166500-4

Detailed Description

Enhance your connectivity with our TANDEM SPR. F. CRIMP Socket, designed for Cable Mount (Free-Hanging) installation. This high-performance contact boasts a durable construction, ideal for Power & Signal circuit applications. With a contact amperage of 3A and gold plating on the mating area, it ensures reliable conductivity. Operating smoothly in a wide temperature range from -65 to 105°C (-85 to 221°F), it's a versatile component for various environments. Suitable for 20-24 AWG wires, this connector supports wire insulation diameters of .91 to 1.37mm, making it compatible with a range of setups. Its straight orientation and Crimp Snap-In housing retention ensure easy and secure assembly. Compliant with RoHS standards, this contact is a dependable choice for your connectivity needs.
