1986693-3

AMP1986693-3
Heilind Number:AMP1986693-3
Manufacturer:TE Connectivity
Manufacturer Number:1986693-3
Datasheet:3DDrawing
ECAD Model:
3D Model

Description:

STR PLUG SPRING TYPE LH 3P, 3.50mm

More >>

Specifications

AttributeValue
Product Category:
Pluggable Terminal Blocks & Headers Pluggable Terminal Block Headers
Manufacturer:TE Connectivity
Manufacturer Part Number:TE Connectivity 1986693-3
Amperage:11 A, 9 A
Gender:Plug
Housing Material:PA 6/6
Number of Contacts:3
Number of Rows:1
Contact Material:Copper Alloy
Pitch:.138 in, 3.5 mm
Voltage:300 V AC
Mount Angle:Vertical
Block Type:Spring Terminal Block
Package Quantity:200
Contact Amperage:11 A
Number of Positions:3
Housing Color:Green
GPL:124
Operating Temperature Range:-40 - 149 °F, -40 - 65 °C
Circuit Application:Power & Signal
Contact Mating Area Plating:Tin over Copper Alloy
GPL Description:Industrial
Connector and Contact Terminate To:Wire & Cable
Product Code:7743
Wire Size:.05 - 2 mm², 14 - 30 AWG
Connector System:Wire to Board
Stacking Configuration:Side Stackable
ECCN:EAR99
Entry Angle:Top
Interlock:Without
Lever Color:Orange
Threaded Flange:Without
Mating Angle:90° (Bottom)/ 270° (Top)
Screw Flange:Without
Screwless Terminal Block:Yes
Wire Protection:With
Part Aliases:1986693-3
SKU:AMP1986693-3

Detailed Description

Easily connect and secure electrical wires with our Straight Plug Spring Type Terminal Block, featuring a Left Hand orientation with 3 positions. Designed for efficient power and signal transmission, this terminal block has a 3.50mm pitch and can accommodate wire sizes ranging from 14 to 30 AWG. With a durable PA 6/6 housing in a vibrant green color, it ensures reliable performance even in industrial settings. The copper alloy contacts with tin plating offer excellent conductivity, while the spring terminal design allows for quick and secure wire termination. Suitable for wave solder processes up to 265°C, this RoHS-compliant terminal block is ideal for various applications, from power distribution to signal routing. With a compact and stackable design, it provides flexibility in circuit layouts, making it a versatile solution for your connectivity needs.
