2-1513472-3

AMP2_1513472_3
Heilind Number:AMP2-1513472-3
Manufacturer:TE Connectivity
Manufacturer Number:2-1513472-3
Datasheet:3D Model (IGS)
ECAD Model:
3D Model

Description:

Stamped Metal Antenna, Dual Band, Bluetooth / Wi-Fi, External Mount, Snap-In, MHF4, Omnidirectional, Single Port, Gain 3 < 6 dBi

More >>

Specifications

AttributeValue
Product Category:
Passives Antennas
Manufacturer:TE Connectivity
Manufacturer Part Number:TE Connectivity 2-1513472-3
Impedance:50 Ω
Polarization:Linear
Protocol:802.11a, 802.11b, 802.11g, 802.11n, Bluetooth, ZigBee
Mounting Style:Snap In
VSWR:3:1
Antenna Type:Stamped Metal
Antenna Termination Type:MHF4
Application:Bluetooth, Wi-Fi
Band Type:Dual Band
Center Frequency:2550 MHz, 5850 MHz
Directionality:Omnidirectional
Frequency Range:2480 - 2620 MHz, 5500 - 6200 MHz
Gain:3 dB
SKU:AMP2-1513472-3

Detailed Description

Ensure seamless connectivity with this RoHS-compliant dual-band antenna, designed for optimal performance in Bluetooth and Wi-Fi applications. Crafted from stamped metal with an omnidirectional design, it offers a gain of 3 dB for enhanced signal strength. Featuring a snap-in mounting style and MHF4 antenna termination, it's easy to install for external use. Operating at frequencies between 2480-2620 MHz and 5500-6200 MHz, it covers a wide range for versatile connectivity. With linear polarization and an impedance of 50 Ω, it ensures reliable transmission. Ideal for ZigBee, Bluetooth, and various 802.11 protocols, it's a crucial component for wireless communication setups.
