MS3456L20-8PW

Heilind Number:	AMP2108994-1
Manufacturer:	Aero-Electric Connector \| Conesys
Manufacturer Number:	MS3456L20-8PW
Datasheet:	Qualification Test Report
ECAD Model:

Description:

Chip Antenna, Multi Band, Cat-M/NB-IoT / Cellular, Internal/Embedded Mount, Surface Mount, Omnidirectional, Single Port, Gain 3 < 6 dBi

More >>

Specifications

Attribute	Value
Product Category:	Passives Antennas
Manufacturer:	Aero-Electric Connector \| Conesys
Manufacturer Part Number:	Aero-Electric Connector \| Conesys MS3456L20-8PW
Impedance:	50 Ω
Polarization:	Linear
Protocol:	EU Triband, LTE, UMTS, US Dual Band, WCDMA
Mounting Style:	Surface Mount
VSWR:	3:1
Antenna Type:	Chip, PCB
Application:	Cat-M/NB-IoT, Cellular, Wi-Fi
Band Type:	Multi Band
Center Frequency:	2200 MHz, 829 MHz
Directionality:	Omnidirectional
Frequency Range:	1710 - 2690 MHz, 698 - 960 MHz
Gain:	2 dB
SKU:	AMP2108994-1

Detailed Description

This RoHS-compliant chip antenna is designed for seamless integration in a variety of devices, offering a 2 dB gain and 3:1 VSWR for efficient signal transmission. With support for LTE, UMTS, EU Triband, US Dual Band, and WCDMA protocols, it ensures broad compatibility. Its multi-band functionality covers frequencies ranging from 1710 to 2690 MHz and 698 to 960 MHz, making it ideal for Cat-M/NB-IoT, cellular, and Wi-Fi applications. Featuring a surface mount design for easy installation, this omnidirectional antenna guarantees reliable performance in diverse environments. Its linear polarization and single-port configuration further enhance signal clarity, while its compact size and 50 Ω impedance optimize space efficiency. Perfect for internal or embedded mounting, it offers a gain of 3-6 dBi, meeting the demands of modern connectivity requirements. Explore the possibilities with this high-performance antenna in your next project.
