213300-1

AMP213300-1
Heilind Number:AMP213300-1
Manufacturer:TE Connectivity
Manufacturer Number:213300-1
Datasheet:Datasheet
ECAD Model:
3D Model

Description:

M SER 34 PASSM KIT(CC,JS)V.35

More >>

Specifications

AttributeValue
Product Category:
Connectors Power Connectors
Manufacturer:TE Connectivity
Manufacturer Part Number:TE Connectivity 213300-1
Series:AMP M Series
Housing Material:Phenolic GF
Contact Type:Pin, Socket
Package Quantity:1
Number of Positions:34
Housing Color:Black
GPL:231
Packaging:Bag
Operating Temperature Range:-55 - 150 °C, -67 - 302 °F
Panel Mount:Without
Sealable:No
GPL Description:Industrial
Connector and Contact Terminate To:Wire & Cable
Product Code:7965
Connector Length:2.05 in, 52.07 mm
Connector System:Cable-to-Cable
Connector Product Type:Housing
ECCN:EAR99
Connector Width:21.03 mm, .828 in
Accepts Cable Diameter:13.82 mm, .544 in
Connector and Housing Type:Plug
Material Flammability Standard:UL 94V-0
Part Aliases:AMP-0-0213300-1,A12470-000 213300-1
SKU:AMP213300-1

Detailed Description

Elevate your industrial connectivity with our AMP M Series 34-Position Pass-Through Kit. Engineered for durability, the housing is constructed of UL 94V-0 rated Phenolic GF in sleek black, ensuring reliable performance in a wide operating temperature range from -55 to 150°C (-67 to 302°F). This kit, designed for cable-to-cable connections, features a combination of socket and pin contacts, accommodating wires with a diameter of up to 13.82mm (.544 in). With a compact yet sturdy design, it's perfect for demanding industrial applications. RoHS compliant, it meets stringent environmental standards, guaranteeing both performance and sustainability. Upgrade your connectivity solutions with this essential component.
