2287288-1

AMP2287288-1
Heilind Number:AMP2287288-1
Manufacturer:TE Connectivity
Manufacturer Number:2287288-1
Datasheet:3DDrawing
ECAD Model:
3D Model

Description:

SW RA RCP ASM, 4P, 8C, 85O, PIC, SR FP

More >>

Specifications

AttributeValue
Product Category:
Backplane Connectors & Accessories Backplane Connectors
Manufacturer:TE Connectivity
Manufacturer Part Number:TE Connectivity 2287288-1
Series:STRADA Whisper 3.9mm
Amperage:.4 A
Connector Type:Receptacle
Gender:Receptacle
Housing Material:LCP (Liquid Crystal Polymer)
Number of Rows:4
Termination Method:Through Hole - Press-Fit
Contact Material:Copper Alloy
Pitch:.098 in, 2.5 mm
Voltage:80 V AC, 80 V DC
Contact Type:Socket
Contact Length:23.1 mm
Row Spacing:.154 in, 3.9 mm
Impedance:85 Ω
PCB Hole Diameter:.039 in, 1 mm
Number of Pairs:32
Number of Positions:64
Data Rate:56 Gb/s
Housing Color:Black
Mount Orientation:Right Angle
Termination Type:Without
GPL:Z82
Shield Material:Copper Alloy
Packaging:Tube
Operating Temperature Range:-55 - 105 °C, -67 - 221 °F
Circuit Application:Signal
Contact Mating Area Plating:Gold Flash over Palladium Nickel
PCB Retention:With
PCB Thickness (Recommended):.039 in, 1 mm
Connector Height:11.5 mm, .453 in
PCB Retention Type:Action/Compliant Tail
Sealable:No
Mating Alignment:With
Mating Alignment Type:Keyed
GPL Description:Data and Devices
Connector and Contact Terminate To:Printed Circuit Board
Product Code:M284
Number of Columns:8
Number of Power Positions:64
Number of Signal Positions:64
Preloaded:No
Contact Design:Dual Beam
Contact Transmits:Signal (Data)
Connector Length:.909 in
Connector System:Board to Board
UL Agency Certification:E28476
Contact Termination Plating:Tin
Stackable:No
Connector Product Type:Connector
Pairs Per Column:4, 8
Contact Style:Press-Fit
Board to Board Configuration:Right Angle
Mating Retention:Without
PCB Mount Alignment Type:Action/Compliant Tail
Make First / Break Last:No
Shroud Type:No
Post Type:Through Hole - Press-Fit
Type:3.99 mm Whisper
Number of Ground Positions:40
Guide Hardware:Without
Durability Rating (Cycles):200 Cycles
Signal Arrangement:Differential
Voltage Rating (UL):80 V AC
Material Flammability Standard:UL 94V-0
Part Aliases:2287288-1
SKU:AMP2287288-1

Detailed Description

Introducing the STRADA Whisper 3.9mm Receptacle Assembly, a crucial component for high-speed signal transmission in electronic devices. This assembly features a robust design with 4 rows and 8 columns, accommodating 64 power and signal positions. The innovative Press-Fit termination method ensures secure and reliable connections on a 1mm thick PCB. With a contact design of Dual Beam technology and gold flash plating, it guarantees optimal signal integrity at a blazing 56 Gb/s data rate. Operating within a wide temperature range of -55 to 105°C, this connector is suitable for diverse industrial applications. RoHS compliant and UL 94V-0 certified, it meets stringent quality standards for environmental sustainability and fire safety. Upgrade your system with the STRADA Whisper 3.9mm Receptacle Assembly for seamless and efficient data transmission.
