282808-6

Heilind Number:	AMP282808-6
Manufacturer:	TE Connectivity
Manufacturer Number:	282808-6
Datasheet:	Catalog Section
ECAD Model:

Description:

TERMI-BLOK PLUG STACKING 6P.10

More >>

Specifications

Attribute	Value
Product Category:	Connectors Terminal Blocks
Manufacturer:	TE Connectivity
Manufacturer Part Number:	TE Connectivity 282808-6
Amperage:	15 A
Gender:	Plug
Housing Material:	PA 6/6
Number of Rows:	1
Contact Material:	Phosphor Bronze
Pitch:	10 mm, .394 in
Voltage:	600 V AC
Mount Angle:	Right Angle
Block Type:	Stacking Plug
Screw Size:	M3
Contact Amperage:	15 A
Number of Positions:	6
Housing Color:	Green
GPL:	124
Operating Temperature Range:	-40 - 105 °C, -40 - 221 °F
Circuit Application:	Power & Signal
Contact Mating Area Plating:	Tin
GPL Description:	Industrial
Connector and Contact Terminate To:	Wire & Cable
Product Code:	7743
Wire Size:	.03 - 2.5 mm², 12 - 30 AWG
Connector System:	Wire to Board
Screw Material:	Brass
Screw Plating:	Nickel
Body Color:	Green
Entry Angle:	Top
Interlock:	With
Screw Flange:	Without
Screwless Terminal Block:	No
Wire Protection:	With
Part Aliases:	282808-6
SKU:	AMP282808-6

Detailed Description

Easily stack and connect wires with our 6-position TERMI-BLOK Plug, designed for efficient power and signal transmission. Constructed with durable PA 6/6 housing in a vibrant green color, this connector ensures secure and reliable connections in industrial settings. Featuring phosphor bronze contacts with tin plating, it offers excellent conductivity and corrosion resistance. With a 10mm pitch and right-angle mount angle, it's perfect for space-saving installations. Operating in a wide temperature range from -40°C to 105°C, this connector is suitable for various environments. RoHS compliant and suitable for wire sizes ranging from 12 to 30 AWG, it's a versatile solution for wire-to-board connections. Upgrade your system with this high-quality stacking plug.
