282856-3

AMP282856-3
Heilind Number:AMP282856-3
Manufacturer:TE Connectivity
Manufacturer Number:282856-3
Datasheet:Datasheet
ECAD Model:
3D Model

Description:

TERMI-BLOK PCB MOUNT 3P

More >>

Specifications

AttributeValue
Product Category:
Pluggable Terminal Blocks & Headers Pluggable Terminal Block Headers
Manufacturer:TE Connectivity
Manufacturer Part Number:TE Connectivity 282856-3
Amperage:24 A
Gender:Header
Housing Material:PA 6/6
Number of Contacts:3
Number of Rows:1
Mount Type:Board Mount
Contact Material:Brass
Pitch:.197 in, 5 mm
Voltage:300 V AC
Mount Angle:Straight
Block Type:Stacking w/interlock
Screw Size:M3
Package Quantity:200
Contact Amperage:24 A
Number of Positions:3
Housing Color:Green
GPL:124
Tail Length:.138 in, 3.5 mm
Packaging:Box
Operating Temperature Range:-40 - 110 °C, -40 - 230 °F
Circuit Application:Power & Signal
Contact Mating Area Plating:Tin
GPL Description:Industrial
Connector and Contact Terminate To:Printed Circuit Board
Product Code:7742
Wire Size:.05 - 3 mm², 12 - 30 AWG
Connector System:Wire to Board
Screw Material:Brass
Stacking Configuration:Side Stackable
ECCN:EAR99
Screw Plating:Nickel
Entry Angle:Side
Interlock:With
Closed End:Without
Stacked Levels:Without
Contact Mount Style:Through Hole
Screw Flange:Without
Screwless Terminal Block:No
Wire Protection:With
Part Aliases:282856-3
SKU:AMP282856-3

Detailed Description

Efficiently connect power and signal circuits with our TERMI-BLOK PCB Mount 3P header, featuring a durable PA 6/6 housing in a vibrant green color. With three contacts arranged in a single row at a 5mm pitch, this straight-mount terminal block is ideal for board mounting applications. Each contact, crafted from high-quality brass with tin plating, ensures reliable conductivity and can accommodate wire sizes ranging from 12 to 30 AWG. Operating within a wide temperature range of -40 to 110°C, this terminal block is suitable for industrial environments. With a 24A amperage rating and 300V AC voltage capacity, it offers robust performance for various power and signal transmission needs. Compliant with RoHS standards, this connector is also environmentally friendly, making it a responsible choice for your connectivity requirements.
