796980-7

AMP796980-7
Heilind Number:AMP796980-7
Manufacturer:TE Connectivity
Manufacturer Number:796980-7
Datasheet:Datasheet
ECAD Model:
3D Model

Description:

7 POS TERMI-BLOK VERT HDR 7.62

More >>

Specifications

AttributeValue
Product Category:
Connectors Terminal Blocks
Manufacturer:TE Connectivity
Manufacturer Part Number:TE Connectivity 796980-7
Amperage:15 A
Gender:Header
Housing Material:PA 6/6
Number of Rows:1
Mount Type:Board Mount
Contact Material:Copper Alloy
Pitch:.3 in, 7.62 mm
Voltage:300 V AC
Mount Angle:Vertical
Block Type:PCB Mount
Package Quantity:50
Contact Amperage:15 A
Number of Positions:7
Housing Color:Green
GPL:124
Tail Length:.138 in, 3.5 mm
Operating Temperature Range:-40 - 105 °C, -40 - 221 °F
Circuit Application:Power & Signal
Contact Mating Area Plating:Tin
GPL Description:Industrial
Connector and Contact Terminate To:Printed Circuit Board
Product Code:7742
Connector System:Wire to Board
ECCN:EAR99
Header Type:Shrouded
Interlock:Without
Closed End:With
Threaded Flange:Without
Contact Mount Style:Through Hole
Screw Flange:Without
Screwless Terminal Block:No
Part Aliases:796980-7
SKU:AMP796980-7

Detailed Description

Easily connect power and signal components with this green PCB mount terminal block. With a 7.62mm pitch and 15A amperage, it's suitable for various applications. Featuring a housing made of durable PA 6/6, copper alloy contacts, and tin plating, it ensures reliable performance. With its wave solder capability and RoHS compliance, it's environmentally friendly and easy to integrate into your projects. The 50-piece package quantity makes it convenient for bulk installations, while the -40 to 105°C operating temperature range guarantees suitability for diverse environments. Its shrouded header design with a closed end offers added protection, perfect for industrial use. Upgrade your wire-to-board connections with this versatile terminal block.
