| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | TE Connectivity | Raychem |
| Manufacturer Part Number: | TE Connectivity | Raychem 037454-000 |
| Outside Diameter: | .049 - .052 in, 1.25 - 1.32 mm |
| Insulation Material: | Radiation-Crosslinked, Modified ETFE |
| Number of Conductors: | 1 |
| Number of Strands: | 19 |
| Conductor Material: | Tin-Plated Copper |
| Operating Temperature Range: | -65 - 200 °C |
| Conductor Outside Diameter: | .037 in, .94 mm |
| Wire Size: | 20 AWG, .52 mm² |
| Rated Voltage: | 600 V |
| Jacket Color: | Brown |
| Insulation Thickness: | .15 mm |
| SKU: | RYC037454-000 |
037454-000
| Heilind Number: | RYC037454-000 |
| Manufacturer: | TE Connectivity | Raychem |
| Manufacturer Number: | 037454-000 |
| Datasheet: | Product Specification |
| ECAD Model: | |
Specifications
Detailed Description
Discover the FLHTC0311-20-1, a high-performance single-conductor wire designed for demanding applications. With a wire size of 20 AWG (.52 mm²) and 19 strands of tin-plated copper, this wire ensures reliable conductivity. The brown Radiation-Crosslinked, Modified ETFE insulation offers excellent protection, with a thickness of .15 mm. Operating at temperatures ranging from -65 to 200 °C, it is suitable for use in extreme environments. Meeting a rated voltage of 600 V, this wire guarantees safe and efficient performance. Its slender outside diameter of .049 - .052 in (1.25 - 1.32 mm) makes it versatile for various installations. Ideal for hookup and equipment applications, the FLHTC0311-20-1 is a must-have in your wire collection.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
