2007804-2

AMP2007804-2
Heilind Number:AMP2007804-2
Manufacturer:TE Connectivity
Manufacturer Number:2007804-2
Datasheet:Drawing
ECAD Model:
3D Model

Description:

IMP100S,H,V3P16C,UG,OEW39,4.9

More >>

Specifications

AttributeValue
Product Category:
Backplane Connectors & Accessories Backplane Connectors
Manufacturer:TE Connectivity
Manufacturer Part Number:TE Connectivity 2007804-2
Series:IMPACT
Amperage:.75 A
Connector Type:Header
Gender:Plug
Housing Material:LCP - GF (Liquid Crystal Polymer)
Number of Rows:9
Mount Type:Board Mount
Termination Method:Through Hole - Press-Fit
Contact Material:Copper Alloy
Pitch:.075 in, 1.9 mm
Voltage:30 V AC, 30 V DC
Contact Type:Pin
Contact Length:.193 in, 30.3 mm, 4.9 mm
Row Spacing:.053 in, 1.35 mm
Impedance:100 Ω
PCB Hole Diameter:.015 in, .39 mm
Number of Pairs:48
Number of Positions:144
Data Rate:20 - 25 Gb/s
Housing Color:Black
Mount Orientation:Vertical
GPL:K74
Tail Length:.055 in, 1.4 mm
Packaging:Box & Tube, Package
Operating Temperature Range:-55 - 85 °C, -67 - 185 °F
Circuit Application:Signal
Contact Mating Area Plating:Gold
Contact Mating Area Plating Thickness:29.92 µin, .76 µm
PCB Retention:With
Contact Underplating Material:Nickel
PCB Thickness (Recommended):1 mm
Connector Height:11.95 mm, .47 in
PCB Retention Type:Action/Compliant Tail
Sealable:No
Mating Alignment:With
Mating Alignment Type:Polarization
GPL Description:Data and Devices
Connector and Contact Terminate To:Printed Circuit Board
Product Code:L346
Number of Columns:16
Number of Signal Positions:96
Contact Design:Dual Beam
Contact Layout:Inline
Contact Transmits:Signal (Data)
Connector Length:1.193 in
Connector System:Board to Board
UL Agency Certification:E28476
Contact Termination Plating:Tin
Stackable:No
Connector Product Type:Connector
Pairs Per Column:3
Contact Style:Press-Fit
Board to Board Configuration:Right Angle
Contact Underplating Thickness:1.27 µm, 50 µin
PCB Contact Termination Area Plating Finish:Matte
Connector Width:16.7 mm, .657 in
Mating Retention:Without
Make First / Break Last:No
Shroud Type:Partial
PCB Contact Termination Area Plating Thickness:30 - 60 µin, .76 - 1.52 µm
Guide Location:Unguided
Number of Ground Positions:48
End Wall Location:Open
Guide Hardware:Without
Signal Arrangement:Differential
Material Flammability Standard:UL 94V-0
Part Aliases:2007804-2
SKU:AMP2007804-2

Detailed Description

Experience seamless signal transmission with the IMPACT IMP100S Board-to-Board Connector, designed for high-speed data applications. Featuring a dual-beam contact design and a 100Ω impedance, this connector ensures reliable connectivity with 96 signal positions and 48 ground positions in a right-angle configuration. With a data rate of 20-25 Gb/s and UL 94V-0 flammability rating, it meets stringent performance and safety standards. The connector is suitable for use in demanding environments, with an operating temperature range of -55 to 85°C. Its Press-Fit termination method and gold plating on contact mating areas guarantee robust and low-resistance connections. Perfect for board-level interconnects, this black LCP-GF housing connector is RoHS compliant, offering a sustainable solution for your connectivity needs.
