284511-4

AMP284511-4
Heilind Number:AMP284511-4
Manufacturer:TE Connectivity
Manufacturer Number:284511-4
Datasheet:Datasheet
ECAD Model:
3D Model

Description:

4 POS TERMI-BLOK PLUG C. VITI

More >>

Specifications

AttributeValue
Product Category:
Pluggable Terminal Blocks & Headers Pluggable Terminal Block Headers
Manufacturer:TE Connectivity
Manufacturer Part Number:TE Connectivity 284511-4
Amperage:11 A
Gender:Plug
Housing Material:PA 6/6
Number of Contacts:4
Number of Rows:1
Contact Material:Phosphor Bronze
Pitch:.15 in, 3.81 mm
Voltage:300 V AC
Mount Angle:Right Angle
Block Type:None
Screw Size:M2
Package Quantity:150
Contact Amperage:11 A
Number of Positions:4
Housing Color:Green
GPL:124
Operating Temperature Range:-40 - 105 °C, -40 - 221 °F
Circuit Application:Power & Signal
Contact Mating Area Plating:Tin
GPL Description:Industrial
Connector and Contact Terminate To:Wire & Cable
Product Code:7743
Wire Size:.05 - 2 mm², 14 - 30 AWG
Connector System:Wire to Board
Screw Material:Brass
ECCN:EAR99
Screw Plating:Nickel
Entry Angle:Side
Interlock:Without
Threaded Flange:With
Screw Flange:With
Screwless Terminal Block:No
Wire Protection:With
Part Aliases:1317429 284511-4
SKU:AMP284511-4

Detailed Description

Enhance your power and signal connections with this high-quality terminal block header. Designed for durability and efficiency, it features four contacts in a single row for easy installation. The green housing is made of PA 6/6 for reliable performance, while the phosphor bronze contact material ensures excellent conductivity. With a voltage rating of 300V AC and an amperage of 11A, this terminal block header is suitable for industrial applications. Its right-angle mount angle and side entry angle provide versatility in installation, and the threaded flange with screw flange guarantees secure attachment. RoHS compliant and suitable for wire sizes ranging from 14 to 30 AWG, this terminal block header is a dependable choice for your connectivity needs.
