796641-8

AMP796641-8
Heilind Number:AMP796641-8
Manufacturer:TE Connectivity
Manufacturer Number:796641-8
Datasheet:Datasheet
ECAD Model:
3D Model

Description:

8 POS 5.0 MM R/A PLUG,TRM BLK

More >>

Specifications

AttributeValue
Product Category:
Connectors Terminal Blocks
Manufacturer:TE Connectivity
Manufacturer Part Number:TE Connectivity 796641-8
Amperage:15 A
Gender:Plug
Housing Material:PA 6/6
Number of Rows:1
Mount Type:Board Mount
Contact Material:Phosphor Bronze
Pitch:.197 in, 5 mm
Voltage:300 V AC
Mount Angle:Right Angle
Block Type:Stacking Plug
Screw Size:M3
Package Quantity:100
Contact Amperage:15 A
Number of Positions:8
Housing Color:Black
GPL:124
Packaging:Box
Operating Temperature Range:-40 - 105 °C, -40 - 221 °F
Circuit Application:Power & Signal
Contact Mating Area Plating:Tin
GPL Description:Industrial
Connector and Contact Terminate To:Wire & Cable
Product Code:7743
Wire Size:.05 - 3 mm², 12 - 30 AWG
Connector System:Wire to Board
Screw Material:Brass
Stacking Configuration:Side Stackable
ECCN:EAR99
Screw Plating:Nickel
Entry Angle:Side
Interlock:Without
Screw Flange:Without
Screwless Terminal Block:No
Wire Protection:With
Part Aliases:796641-8
SKU:AMP796641-8

Detailed Description

Easily connect power and signal wires with this industrial-grade Stacking Plug. Ideal for board mount applications, this connector features a right-angle mount, black housing, and a side stackable design. With a contact amperage of 15 A and a voltage rating of 300 V AC, it ensures reliable performance in a wide range of operating temperatures. The phosphor bronze contacts with tin plating accommodate wire sizes ranging from 12 to 30 AWG, making it versatile for various applications. With a package quantity of 100, it's perfect for large-scale projects while being RoHS compliant for environmental responsibility. Whether for commercial or industrial use, this Wire to Board connector is a dependable choice for your connectivity needs.
