09185346813

HRT09185346813
Heilind Number:HRT09185346813
Manufacturer:HARTING
Manufacturer Number:09185346813
Datasheet:Datasheet
ECAD Model:
3D Model

Description:

SEK, Female connector; Rated current: 2.5A; Thermoplastic resin (PBT), Beige; Contacts: 34; Performance level: 2

More >>

Specifications

AttributeValue
Product Category:
FFC, FPC, Ribbon & IDT Connectors IDC Ribbon Cable Connectors
Manufacturer:HARTING
Manufacturer Part Number:HARTING 09185346813
Series:SEK
Gender:Female
Housing Material:Plastic
Number of Contacts:34
Number of Rows:2
Termination Method:IDC
Contact Material:Copper Alloy
Contact Plating:Gold Over Nickel, Tin Over Nickel
Maximum Operating Temperature:125 °C
Minimum Operating Temperature:-55 °C
Pitch:1.27 mm, 2.54 mm
Housing Color:Gray
Mating Cycles:250 cycle
Wire Size:28 - 26 AWG
Performance Level:Class II
Current Rating:2.5 A
Voltage Rating:1 kV
SKU:HRT09185346813

Detailed Description

SEK Female Connector 09185346813 is a high-performance component designed for reliable and efficient connectivity in electronic systems. With a rated current of 2.5A, it ensures safe power transmission. Made from durable thermoplastic resin (PBT) in a sleek beige hue, this connector features 34 gold-plated contacts for optimal conductivity. Its housing, crafted from quality plastic, accommodates 34 contacts in 2 rows, facilitating easy installation via IDC termination method. Operating flawlessly in temperatures ranging from -55°C to 125°C, it guarantees stability in diverse environments. Compliant with RoHS standards, this connector is environmentally friendly. Suitable for a variety of applications, it is an essential component for high-reliability systems.
