1586102-3

AMP1586102-3
Heilind Number:AMP1586102-3
Manufacturer:TE Connectivity
Manufacturer Number:1586102-3
Datasheet:Datasheet
ECAD Model:
3D Model

Description:

3P PLUG VAL-U-LOK SR PM V0

More >>

Specifications

AttributeValue
Product Category:
Connectors Power Connectors
Manufacturer:TE Connectivity
Manufacturer Part Number:TE Connectivity 1586102-3
Housing Material:Nylon 6/6
Number of Rows:1
Mount Type:Panel
Termination Method:Crimp
Pitch:.165 in, 4.2 mm
Voltage:600 V AC
Contact Type:Pin
Package Quantity:1000
Cable Type:Discrete Wire
Number of Positions:3
Housing Color:White
GPL:G31
Packaging:Bag
Operating Temperature Range:-40 - 105 °C, -40 - 221 °F
Circuit Application:Power & Signal
Connector Height:.291 in, 7.4 mm
Sealable:No
GPL Description:Appliances
Connector and Contact Terminate To:Wire & Cable
Product Code:K924
Contact Layout:Inline
Connector Length:13.8 mm, .543 in
Connector System:Wire to Wire
CSA Agency Certification:208567
Connector Product Type:Housing
ECCN:EAR99
Connector Width:23.9 mm, .94 in
Accepts Wire Insulation Diameter:.047 - .122 in, 1.2 - 3.1 mm
Insertion Force:15 Newton
Contact Retention:Without
Glow Wire Rating:Standard Part - Not Glow Wire
Circuit Identification Feature:With
VDE Tested:No
Connector and Housing Type:Plug
Standards Met:UL CSA
Material Flammability Standard:UL 94V-0
Part Aliases:1586102-3
SKU:AMP1586102-3

Detailed Description

Enhance power and signal connectivity with our UL and CSA certified Connector Housing, perfect for a variety of applications. Featuring a durable Nylon 6/6 construction in a sleek white hue, this single-row panel mount connector is designed for seamless integration. With a crimp termination method and 4.2 mm pitch, it offers reliable performance and easy installation. Ideal for discrete wire setups, it accommodates three positions with pin contacts, ensuring efficient power transmission. Operating flawlessly in temperatures ranging from -40 to 105°C, it's a versatile solution for both residential and industrial use. With a package quantity of 1000, it's perfect for large-scale projects. RoHS compliant and meeting UL 94V-0 flammability standards, this connector prioritizes safety and environmental responsibility. Upgrade your connectivity with this essential component for appliances and more.
