1801174-2

AMP1801174-2
Heilind Number:AMP1801174-2
Manufacturer:TE Connectivity
Manufacturer Number:1801174-2
Datasheet:Drawing
ECAD Model:
3D Model

Description:

2W TAB HP CONNECTOR BLUE

More >>

Specifications

AttributeValue
Product Category:
Automotive Connectors & Accessories Automotive Connector Accessories
Manufacturer:TE Connectivity
Manufacturer Part Number:TE Connectivity 1801174-2
Series:Sensor Flat Contact System
Gender:Housing for male terminals
Number of Rows:1
Pitch:.131 in, 3.33 mm
Voltage:16 V DC
IP Rating:IP69K
Strain Relief:Add By Accessory
Polarization:Yes
Body Material:PBT GF
Number of Positions:2
GPL:N76
Operating Temperature Range:-40 - 150 °C, -40 - 302 °F
Circuit Application:Signal
Sealable:Yes
GPL Description:Automotive
Product Code:M088
Connector System:Wire to Wire
Length:.685 in
Cable Exit Angle:180°
Height:17.6 mm, .693 in
Width:2.197 in, 55.8 mm
Mating Tab Width:.025 in, .059 in, 1.5 mm, .64 mm
Nominal Voltage Architecture:12 V
Body Color:Blue
Serviceable:Yes
Mounting Feature:Without
Terminal Position Assurance:Yes
Connector Position Assurance Capable:No
Hybrid Connector :No
Primary Locking Feature:Integrated in Housing
Material Flammability Standard:UL 94-HB
Part Aliases:1801174-2
SKU:AMP1801174-2

Detailed Description

Enhance signal connectivity in automotive applications with this Sensor Flat Contact System, designed for housing male terminals with a pitch of 3.33 mm. Crafted from durable PBT GF material, it ensures reliability in harsh environments, with an IP69K rating for dust and water resistance. Operating flawlessly in temperatures ranging from -40 to 150°C, it guarantees optimal performance. With two positions available, it offers versatility in circuit applications and features a 180° cable exit angle for convenient installation. The integrated strain relief and polarization mechanism ensure secure and accurate connections, while the blue housing color adds a touch of visual distinction. Compliant with RoHS standards, this connector system is both eco-friendly and serviceable, making it a dependable choice for automotive connectivity needs.
