3-1534796-4

AMP3-1534796-4
Heilind Number:AMP3-1534796-4
Manufacturer:TE Connectivity
Manufacturer Number:3-1534796-4
Datasheet:Datasheet
ECAD Model:
3D Model

Description:

AMP DUOPLUG MK2 CONNECTOR 4P S

More >>

Specifications

AttributeValue
Product Category:
Board To Board PCB Connectors Card Edge Connectors
Manufacturer:TE Connectivity
Manufacturer Part Number:TE Connectivity 3-1534796-4
Amperage:2 A
Gender:Female
Housing Material:PA 6 GF
Number of Rows:1
Mount Type:Cable Mount (Free-Hanging)
Termination Method:Insulation Displacement Crimp (IDC)
Contact Material:Copper Tin
Contact Plating:Tin
Body Orientation:Right Angle
Pitch:.098 in, 2.5 mm
Voltage:250 V
Contact Type:Socket
Package Quantity:3080
Number of Positions:4
Housing Color:Natural
Mount Orientation:Right Angle
GPL:405
Packaging:Tray
Operating Temperature Range:-40 - 110 °C, -40 - 230 °F
Circuit Application:Signal
Contact Mating Area Plating:Tin
Contact Mating Area Plating Thickness:3 - 6 µm
Panel Mount:Without
PCB Retention:Without
PCB Contact Termination Area Plating:Tin
PCB Thickness (Recommended):.059 in, 1.5 mm
Connector Height:.287 in, 7.3 mm
Mating Alignment:With
Mating Alignment Type:Keyed
GPL Description:Appliances
Connector and Contact Terminate To:Printed Circuit Board
Product Code:K358
Wire Size:22 - 24 AWG, .22 - .35 mm²
Connector System:Wire to Board
ECCN:EAR99
Connector Contact Load Condition:Fully Loaded
Mating Retention:Without
PCB Mount Alignment:Without
Card Entry Location:Side
Accepts Wire Insulation Diameter:.047 - .063 in, 1.2 - 1.6 mm
Housing Configuration:Both Ends Opened
Contact Retention:With
Compatible Wire / Cable Type:Discrete Wire
Contact Retention Type in Housing:Locking Lance
Insulation Displacement Slots:4
Connector and Housing Type:Receptacle
Standards Met:UL 94V-2
Material Flammability Standard:UL 94V-2
Part Aliases:3-1534796-4
SKU:AMP3-1534796-4

Detailed Description

The AMP DUOPLUG MK2 CONNECTOR 4P S is a high-quality female connector designed for signal applications. With a housing made of durable PA 6 GF material and UL 94V-2 flammability standard compliance, it ensures safety and reliability. Featuring a right-angle body orientation and cable mount termination method, it offers flexibility in installation. The IDC termination method and copper tin contacts with tin plating guarantee efficient signal transmission. With a pitch of 2.5mm and a voltage rating of 250V, it is suitable for various electronic systems. This connector, in natural housing color, comes in a package quantity of 3080, making it ideal for large-scale production. RoHS compliant and operating in a wide temperature range, it meets industry standards for environmental responsibility and performance. Perfect for wire-to-board connections in appliances and other electronic devices, this AMP connector is a dependable choice for your connectivity needs.
