3-1534797-3

AMP3-1534797-3
Heilind Number:AMP3-1534797-3
Manufacturer:TE Connectivity
Manufacturer Number:3-1534797-3
Datasheet:Datasheet
ECAD Model:
3D Model

Description:

AMP DUOPLUG MK2 CONNECTOR 13P

More >>

Specifications

AttributeValue
Product Category:
Board To Board PCB Connectors Card Edge Connectors
Manufacturer:TE Connectivity
Manufacturer Part Number:TE Connectivity 3-1534797-3
Amperage:2 A
Housing Material:PA 6 GF
Number of Rows:1
Mount Type:Cable Mount (Free-Hanging)
Termination Method:Insulation Displacement Crimp (IDC)
Contact Material:CuSn4
Pitch:.098 in, 2.5 mm
Voltage:50 V
Contact Type:Socket
Package Quantity:1078
Number of Positions:13
Housing Color:Natural
Mount Orientation:Right Angle
GPL:405
Packaging:Tray
Operating Temperature Range:-40 - 110 °C, -40 - 230 °F
Circuit Application:Signal
Contact Mating Area Plating:Tin
Contact Mating Area Plating Thickness:3 - 6 µm
Panel Mount:Without
PCB Retention:Without
PCB Contact Termination Area Plating:Tin
PCB Thickness (Recommended):.059 in, 1.5 mm
Connector Height:.287 in, 7.3 mm
Mating Alignment:With
Mating Alignment Type:Keyed
GPL Description:Appliances
Connector and Contact Terminate To:Printed Circuit Board
Product Code:K358
Wire Size:22 - 24 AWG, .22 - .35 mm²
Connector System:Wire to Board
ECCN:EAR99
Connector Contact Load Condition:Fully Loaded
Mating Retention:Without
Card Entry Location:Side
Accepts Wire Insulation Diameter:.047 - .063 in, 1.2 - 1.6 mm
Housing Configuration:Both Ends Opened
Contact Retention:With
Compatible Wire / Cable Type:Discrete Wire
Contact Retention Type in Housing:Locking Lance
Connector and Housing Type:Receptacle
Material Flammability Standard:UL 94V-2
Part Aliases:3-1534797-3
SKU:AMP3-1534797-3

Detailed Description

Introducing the AMP DUOPLUG MK2 Connector, a versatile solution for your connectivity needs. With 13 contact positions and a 2A amperage rating, this connector is ideal for signal applications. Its durable PA 6 GF housing in a natural color meets UL 94V-2 flammability standards, ensuring safety and reliability. Featuring insulation displacement crimp termination and a 2.5mm pitch, it offers easy installation on PCBs. The connector's contact sockets, plated with tin for optimal conductivity, accommodate wire sizes ranging from 22-24 AWG. Operating in temperatures from -40 to 110°C, it is suitable for various environments. Designed for wire-to-board applications, this connector is RoHS compliant, making it an environmentally friendly choice for your projects. With its tray packaging and 1078-piece quantity, it's ready for large-scale production. Elevate your connectivity with the AMP DUOPLUG MK2 Connector.
