1586101-3

AMP1586101-3
Heilind Number:AMP1586101-3
Manufacturer:TE Connectivity
Manufacturer Number:1586101-3
Datasheet:Datasheet
ECAD Model:
3D Model

Description:

3P PLUG VAL-U-LOK SR PM V2

More >>

Specifications

AttributeValue
Product Category:
Connectors Power Connectors
Manufacturer:TE Connectivity
Manufacturer Part Number:TE Connectivity 1586101-3
Housing Material:Nylon 6/6
Number of Rows:1
Mount Type:Panel
Termination Method:Crimp
Pitch:.165 in, 4.2 mm
Voltage:600 V AC
Contact Type:Pin
Package Quantity:1000
Cable Type:Discrete Wire
Number of Positions:3
Housing Color:Natural
GPL:G31
Packaging:Bag
Operating Temperature Range:-40 - 105 °C, -40 - 221 °F
Circuit Application:Power & Signal
Connector Height:.291 in, 7.4 mm
Sealable:No
GPL Description:Appliances
Connector and Contact Terminate To:Wire & Cable
Product Code:K924
Contact Layout:Inline
Connector Length:13.8 mm, .543 in
Connector System:Wire to Wire
CSA Agency Certification:208567
Connector Product Type:Housing
ECCN:EAR99
Connector Width:23.9 mm, .94 in
Accepts Wire Insulation Diameter:.047 - .122 in, 1.2 - 3.1 mm
Insertion Force:15 Newton
Contact Retention:Without
Glow Wire Rating:Standard Part - Not Glow Wire
Circuit Identification Feature:With
VDE Tested:No
Connector and Housing Type:Plug
Standards Met:CSA UL
Material Flammability Standard:UL 94V-2
Part Aliases:1586101-3
SKU:AMP1586101-3

Detailed Description

Meet your power and signal connection needs with our versatile housing connector. Designed for panel mounting, this durable connector features a single row with three positions for seamless integration. Crafted from UL 94V-2 rated Nylon 6/6, it ensures reliable performance in a wide temperature range from -40 to 105°C (-40 to 221°F). With a pitch of 4.2mm (.165 in) and a voltage rating of 600V AC, it's suitable for various applications, including appliances. The crimp termination method and acceptance of wire insulation diameters ranging from 1.2 to 3.1mm (.047 to .122 in) make installation a breeze. This connector, in a natural housing color, is CSA and UL certified for quality assurance and RoHS compliant for environmental responsibility. With a package quantity of 1000, it's ideal for bulk projects. Whether you're working on power or signal circuits, our connector, part of the Wire to Wire system, guarantees efficient and secure connectivity.
