5-104655-1

AMP5-104655-1
Heilind Number:AMP5-104655-1
Manufacturer:TE Connectivity
Manufacturer Number:5-104655-1
Datasheet:Datasheet
ECAD Model:
3D Model

Description:

10 50/50 HDR DRST SFMNT TIN

More >>

Specifications

AttributeValue
Product Category:
PC Board Pin & Receptacle Connectors PCB Pin Headers
Manufacturer:TE Connectivity
Manufacturer Part Number:TE Connectivity 5-104655-1
Series:AMPMODU 50/50 Grid
Amperage:4 A
Housing Material:Thermoplastic
Number of Contacts:10
Number of Rows:2
Termination Method:Surface Mount
Contact Material:Phosphor Bronze
Body Orientation:Straight
Pitch:.05 in, 1.27 mm
Voltage:30 V AC
Contact Type:Pin
Strain Relief:No Strain Relief
Row Spacing:.05 in, 1.27 mm
Package Quantity:56
Contact Amperage:.5 A
Number of Positions:10
Housing Color:Black
Mount Orientation:Vertical
GPL:007
Profile:Standard
Packaging:Box & Tube, Tube
Operating Temperature Range:-65 - 105 °C
Contact Mating Area Plating:Gold
Contact Mating Area Plating Thickness:30 µin
Panel Mount:Without
PCB Retention:With
Contact Underplating Material:Nickel
PCB Contact Termination Area Plating:Tin
PCB Retention Type:Hold-Down Post
Mating Alignment:With
Mating Alignment Type:Keyed
GPL Description:Industrial
Connector and Contact Terminate To:Printed Circuit Board
Product Code:5376
PCB Retention Material:Copper Alloy
PCB Retention Plating Material:Tin over Nickel
Post Size:.46 mm
Mating Post Length:.12 in, 3.048 mm
ECCN:EAR99
Dielectric Withstanding Voltage:300 V AC
Connector Contact Load Condition:Fully Loaded
Contact Shape:Round
Header Type:Shrouded
Connector Assembly Type:PCB Mount Header
Stack Height:.25 in, 6.35 mm
PCB Contact Termination Area Plating Thickness:150 µin
Shrouded End Dimension:.036 in
Shrouded Sides:2
Standards Met:CSA LR7189 UL E28476
Material Flammability Standard:UL 94V-0
Part Aliases:5-104655-1
SKU:AMP5-104655-1

Detailed Description

Introducing the AMPMODU 50/50 Grid series PCB Pin Header, a reliable and high-performance connector for your electronic assemblies. With a straight body orientation and surface mount termination method, it offers easy integration onto your printed circuit boards. Featuring ten gold-plated pin contacts, it ensures excellent conductivity and signal integrity. This industrial-grade connector, in black housing color with UL 94V-0 flammability rating, meets stringent quality standards for safety and performance. With a voltage rating of 30V AC and operating temperature range of -65 to 105 °C, it is suitable for a wide range of applications. RoHS compliant and packaged in tubes for convenience, it is ideal for use in various electronic devices. Trust in the AMPMODU 50/50 Grid series for seamless PCB connectivity.
