1746972-1

AMP1746972-1
Heilind Number:AMP1746972-1
Manufacturer:TE Connectivity
Manufacturer Number:1746972-1
Datasheet:Datasheet
ECAD Model:
3D Model

Description:

GRACE INERTIA CONNECTOR 6.2MM PITCH REC

More >>

Specifications

AttributeValue
Product Category:
Power Connectors Battery & Coin Cell Clips, Contacts & Holders
Manufacturer:TE Connectivity
Manufacturer Part Number:TE Connectivity 1746972-1
Series:GRACE INERTIA 6.2
Accessory Type:Contact
Mount Type:Cable Mount (Free-Hanging)
Termination Method:Crimp
Contact Material:Copper Alloy
Voltage:600 V AC, 600 V DC
Contact Type:Receptacle
Wire Type:Stranded
Package Quantity:2000
Cable Type:Discrete Wire
Contact Amperage:20 A
Termination Type:Crimp
Insulation Resistance:1000 MΩ
GPL:429
Packaging:Reel
Operating Temperature Range:-40 - 105 °C, -40 - 221 °F
Circuit Application:Power
Contact Mating Area Plating:Pre-Tin
GPL Description:Appliances
Connector and Contact Terminate To:Wire & Cable
Product Code:K757
Wire Size:12 - 14 AWG, 2.08 - 3.31 mm²
Connector System:Wire to Wire
Contact Termination Plating:Pre-Tin
ECCN:EAR99
Wire Insulation Support:Without
Accepts Wire Insulation Diameter:.114 - .161 in, 2.9 - 4.1 mm
Contact Retention:With
Glow Wire Rating:Standard Part - Not Glow Wire
For Multiple Crimp:No
Contact Orientation:Straight
Wire Contact Termination Area Plating Material:Pre-Tin
Contact Retention Type in Housing:Locking Lance
Contact Product Type:Contact
Part Aliases:1746972-1
SKU:AMP1746972-1

Detailed Description

Introducing the Grace Inertia Connector, a high-performance solution for seamless power transmission. With a 6.2mm pitch receptacle, this connector offers reliable connectivity in various applications. Designed for cable mount (free-hanging) installation, it features a crimp termination method for easy assembly. Crafted from durable copper alloy, it ensures efficient power transfer at up to 600V AC/DC. Suitable for 12-14 AWG stranded wires, it accommodates wire sizes from 2.08 to 3.31mm². With a contact amperage rating of 20A and insulation resistance of 1000 MΩ, it guarantees optimal performance. Ideal for power circuits in appliances and other devices, this connector operates flawlessly in temperatures ranging from -40 to 105°C (-40 to 221°F). Whether for industrial or residential use, the Grace Inertia Connector is the perfect choice for your power connectivity needs.
