2057630-1

AMP2057630-1
Heilind Number:AMP2057630-1
Manufacturer:TE Connectivity
Manufacturer Number:2057630-1
Datasheet:Datasheet
ECAD Model:
3D Model

Description:

CFP Receptacle Conn Assy

More >>

Specifications

AttributeValue
Product Category:
High Speed Connectors & Components High Speed Cage Accessories
Manufacturer:TE Connectivity
Manufacturer Part Number:TE Connectivity 2057630-1
Series:CFP
Mount Type:Board Mount
Termination Method:Surface Mount
Pitch:.031 in, 8 mm
Number of Positions:148
Data Rate:100 Gb/s
Interface:CFP
GPL:J03
Port Matrix Configuration:1 x 1
Packaging:Reel
Operating Temperature Range:-55 - 85 °C, -67 - 185 °F
Circuit Application:Signal
PCB Thickness (Recommended):.079 in, 2 mm
Sealable:No
GPL Description:Data and Devices
Connector and Contact Terminate To:Printed Circuit Board
Product Code:L622
Body Plating Material:Gold
Connector System:Board to Board
Connector Product Type:Connector
ECCN:EAR99
PCB Mounting Style:Double-Sided (Belly-to-Belly)
Part Aliases:2057630-1
SKU:AMP2057630-1

Detailed Description

Enhance high-speed data transmission with this CFP Receptacle Conn Assy, a crucial component for signal connectivity. Designed for efficient board mounting using surface mount technology, this assembly features 148 positions with a pitch of .8mm, supporting data rates up to 100 Gb/s. Operating reliably in a wide temperature range from -55 to 85°C, it ensures performance in diverse environments. Ideal for signal circuit applications, this gold-plated connector boasts a durable construction and complies with RoHS regulations for environmental responsibility. Its board-to-board interface and double-sided mounting style offer versatility in connectivity setups, making it an essential choice for advanced electronic systems.
